Mimosa Networks

The Market

The increasing market demand for high-speed broadband connectivity and the high cost and time delay in setting up fiber networks has reinvigorated the demand for a disruptive alternative technology to fulfill this need.

The Solution

Mimosa Networks enables fiber-fast broadband connectivity for dense urban and hard-to-reach rural areas for a fraction of the cost of traditional wireless solutions.

Mimosa Point-to-Point (PTP) Solutions

Mimosa is the global technology leader in wireless broadband solutions providing full range of backhaul, access and client wireless solutions.

High Performance Point-to-Point Backhaul

The high-performance PTP backhaul radios B11, B5c, B5 and B24 deliver aggregate speeds of up to 1.5Gbps, with less than 1ms of latency. Mimosa’s unique GPS Sync technology allows collocation and channel reuse.

  • 1.7GBps (PHY) throughput

  • 1.5GBps (IP) throughput

  • GPS Synchronisation

  • Dual-link

  • IP67

Product model vs distance

B5 series Point-to-Point Backhaul

The Mimosa B5 series is the industry’s fastest unlicensed band radio. It is extremely customizable and reliable allowing virtually any antenna (connectorized model) to be used for long-distance backhaul (PTP) within its frequency band.

  • Incredible speed – 1.5GBps (IP)

  • Spectrum Reuse - GPS Sync

  • Mimosa Cloud NMS

  • Low latency – less than 1ms

  • Extended frequency – 4.90 to 6.20GHz

B24 Point-to-Point Backhaul

Breaking through barriers of radio interferences, size and power requirements, the B24 delivers up to 1.5Gbps aggregate speed with latency under 1ms with incredible performance at a disruptive price.

2. ​Backhaul for Last Mile Dedicated Access
  • Incredible speed – 1.5GBps (IP)

  • Spectrum Reuse GPS Sync

  • Mimosa Cloud NMS

  • Low latency – less than 1ms

  • Frequency range – 24.00 to 24.25GHz

C5 series High-Value Industry's Most Versatile, Modular Radio

The Offering industry-leading price performance, the C5c and modular C5x deliver up to 700Mbps and supports an extended frequency range.

  • 866 Mbps (PHY)

  • 700 Mbps (IP)

  • Four Twist-On, Flexible Antenna Options (model C5x)

  • PTP or PTMP modes

  • Extended Frequency - 4.9 to 6.4GHz


C5 series- Backhaul & Client Radio Design

Mimosa Point-to-Multipoint (PTMP) Solution

Compact and elegant, Mimosa’s point-to-multipoint (PTMP) solutions enable operators to provide fiber-fast connectivity to residential and business subscribers. Providing the highest bandwidth per client deployments in the extended frequency range from 4.9 up to 6.4GHz, it integrates GPS sync for spectrum reuse.

A5 Series Access Point

With fast client speeds and great access point capacity, along with local and network-wide spectrum reuse, the connectorized Mimosa A5c delivers the highest possible scale for any unlicensed fixed wireless network. The A5c is perfectly suited for PTMP applications.

  • Fiber Speeds

    • 1+ Gbps (IP) at Access Point

    • 500 Mbps (IP) at client

  • Noise Resistant - Advanced Automatic Gain Control (AGC)

  • Massive Sector Capacity - Outdoor 4x4:4 MIMO

  • Extended Frequency - 4.9 to 6.4GHz
